Data sheet
SPGL: 680g （color）：6005 green （date）:20170807
|
Properties
|
Test method
|
Unit
|
Result
|
|
|
Basic fabric Material
|
Polyester
|
|||
|
Type of Basic fabric
|
1313(20*20)
|
|||
|
Type of coating
|
E-PVC
|
|||
|
Thickness
|
DIN 53353
|
mm
|
0.53
|
|
|
Weight
|
DIN 53352
|
g/ m2
|
689g
|
|
|
Tensile strength
|
DIN 53354
|
N/5cm
|
Warp 3619 |
Weft 2611 |
|
Tear strength
|
DIN 53363
|
N
|
Warp 372 |
Weft 366 |
|
Adhesion
|
DIN 53357
|
N/5cm
|
102/108N
|
|
|
Operating temp |
-20 ~70 ℃ （-4~160℉）
|
|||
|
Option
|
Anti-U.V. Resistance
|
|||
|
Remark
|
Warp/Fill Tolerance +/-10%,The value is average in the lab |
|||
